Rectifier Bridge Plug In Diode Gbp Series Gbp410 With Solder Plated Terminals

Ask Lasest Price
Brand Name :	Julun
Model Number :	GBP410
Certification :	CE/UL/VDE/KC/ROHS
Price :	Negotiable
Payment Terms :	L/C, D/P, T/T,
Supply Ability :	10000/Piece/Weekly
Delivery Time :	7~10 Working days

Add to Cart

Product Details
Company Profile

Rectifier Bridge Plug In Diode Gbp Series Gbp410 With Solder Plated Terminals

GBP series rectifier bridge plug-in diode GBP410 Transient Voltage Suppressor Diode

FEATURES

Surge overload rating - 75 amperes peak
Ideal for printed circuit board
Plastic material has underwriters laboratory
flammability classification 94V-0Mounting position: Any

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave ,60Hz, resistive or inductive load.

For capacitive load, derate current by 20%

CHARACTERISTICS	SY MBOL	GBP4005	GBP401	GBP402	GBP404	GBP406	GBP408	GBP410	UNIT
Maximum Recurrent Peak Reverse Voltage	VRRM	50	100	200	400	600	800	1000	V
Maximum RMS Bridge Input Voltage	VRMS	30	70	140	280	420	560	700	V
Maximum DC Blocking Voltage	VDC	50	100	200	400	600	800	1000	V
Maximum Average Forw ard Rectified Output Current @ TA=50℃	I(AV)	4							A

Peak Forw ard Surage Current 8.3ms Single Half Sine-Wave Super Imposed on Rated Load	IFSM	125							A

Maximum Forw ard Voltage Drop Per Bridge Element at 4.0A Peak	VF	1.1							V

I2t Rating for Fusing(t<8.3ms)	I2t	23.34							A2s
Maximum Reverse Current at Rated DC Blocking Voltage Per Element	IR	10							uA

Maximum Reverse Current at Rated DC Blocking Voltage Per Element TA=100℃	IR	1							mA

Operating Temperature Range	TJ	-55to +150							℃
Storage Temperature Range	TSTG	-55to +150							℃
